X-ray source electronics set XREC20
XREC20 electronics set dedicated for controlling SAX X-ray sources.
- Description
- Technical Data
Description
The XREC20 set comprises 2 units for full control of the SAX X-ray Sources: XREC20-I emission controller and XRHV02-PS high voltage power supply.
The XREC20-I unit controls the emission current of the X-ray source and also the XRHV02-PS high voltage power supply, displaying both the high voltage and emission current on a single display. Unit allows measurement of working time and anode power. The X-ray source electronics set has both operational and standby modes, guaranteeing the most accurate and stable emission at the start of an experiment. Easy firmware update via USB port (XREC20-I). Unit can be remotely controlled via RS232/485 or Ethernet interfaces. Autosave function (XREC20-I unit) for saving your parameters/unit preset and applying them automatically after restart.
XREC20-I
| Supply voltage | 110 or 230 VAC, 50/60 Hz, (power consumption max 1800 W) |
|---|---|
| Emission current range (Ie) | 0 – 100 mA, accuracy 0.1 mA |
| Anode high voltage range (UHV) | 0.5 kV – 15 kV, accuracy 0.1 kV |
| Cathode current (Icath) | 3A in Standby mode up to 20A in Operate mode |
| Anode power limit | 650 W |
| High voltage ramp | 1 – 1000 V/sec |
| Emission curent ramp | 0.1 – 50 mA/sec |
| Interlocks | High vacuum Cooling water (master) X-ray cover |
| Communication Interface | RS232/485, Ethernet |
| Communication protocol | MODBUS-TCP |
| XREC20-I user interface | 7″ TFT display with touchscreen, digital encoder |
| Interface languages | English, German, Polish |
| Dimensions XREC20-I | 483 x 133 x 380 mm (W x H x D), 19″ rack mountable |
| Dimensions XRHV02-PS [mm] | 483 x 88 x 420 (W x H x D), 19″ rack mountable |
| Weight (approx.) | 10 kg |
XRHV02-PS
| Supply voltage | 85 – 260 VAC, 50-60 Hz, |
|---|---|
| Output voltage range Vo | 0 – 15 kV |
| Output current range Io | 0 – 100 mA |
| Max output power | 1.5 kW |
| Polarity | negative |
| Remote control | via indirect coupled analogue I/O (male D-SUB 9) set and monitor 0 – 5 V |
| Protection | over load and short circuit, voltage supply and temperature |
| Dimensions | 483 × 88 × 420 mm (W×H×D), 19″ rack mountable |
| Weight (approx.) | 6.5 kg |
